Can someone double check that the alternator will be wired up okay for DD use?
-Power from ECU to Disty (power) and FI (power) and ALT (B/GY)
-Alternator W/B to LG/W from P5 fuse block
-From alternator (W/G) with a 40amp fuse to the 100amp fuse block
Pablo tested the alternater voltages at the battery and with some throttle it was charging 14volts
hooked up like this;
-12v from battery then a 10amp fuse to disty and FI power and alternator wires (B/GY, W/G)
-Power from ECU to Disty (power) and FI (power) and ALT (B/GY)
-Alternator W/B to LG/W from P5 fuse block
-From alternator (W/G) with a 40amp fuse to the 100amp fuse block
Pablo tested the alternater voltages at the battery and with some throttle it was charging 14volts
hooked up like this;
-12v from battery then a 10amp fuse to disty and FI power and alternator wires (B/GY, W/G)
Last edited:
bullshark524
Member
- :
- 2000 mazda protege es soon to be 2000 mazda protege klze
(unamused)
good job. what was wrong with it?
good job. what was wrong with it?
Sorry, Sean... Yours is next though buddy, gotta keep your head up. I really wish I could help you out more but I don't know jack about wiring...
The power wire we had from the P5 fuse block wasn't giving power to the disty and injectors. So we snipped it and just ran a power wire straight to the disty and FI's. And we also grounded the fuel pump relay. Maybe it was just a combination of a bunch of little things that finally fired it up.
Have you tried that approach? Just giving the disty and FI's power from the battery with a 10amp fuse?
I'm going to try the JDM KLK1 ECU and see if that runs too since it's better suited for the motor.
The power wire we had from the P5 fuse block wasn't giving power to the disty and injectors. So we snipped it and just ran a power wire straight to the disty and FI's. And we also grounded the fuel pump relay. Maybe it was just a combination of a bunch of little things that finally fired it up.
Have you tried that approach? Just giving the disty and FI's power from the battery with a 10amp fuse?
I'm going to try the JDM KLK1 ECU and see if that runs too since it's better suited for the motor.
evan great job, and glad to hear you got it. As for the KL1 ecu does it still use the same MAF? if not u may want to find out which one. Like the Kl55(USDM 94 ecu) uses the KL02 VAF and the KL31/36 ecu uses a JE50 VAF.
CheeseHelmet
Member
How does it drive?
fishdonotbounce
Registered Zombie
- :
- 08.5 CWP Speed3
OH YEA!!!!! Nice work dude!!!!!!!
princess peach
Member
- :
- '92 Miata, '06 MS6
thanks...
the best part was when I stopped the video, all he says is: "ok....... now what?"
bullshark524
Member
- :
- 2000 mazda protege es soon to be 2000 mazda protege klze
well that is a good question. what now?
fishdonotbounce
Registered Zombie
- :
- 08.5 CWP Speed3
Lmao. You guys did some great work. I know you helped him a s*** ton. I can't wait to see this thing in person.
bullshark524
Member
- :
- 2000 mazda protege es soon to be 2000 mazda protege klze
oh he was checking evans heartbeat? i thought they were getting a little homo =)
Haha! No homo. My heart was pounding and my hands were shaking. Pablo was a HUGE help and did 90% of the wiring, he would just say "This wire goes there." and I'd connect them. And of course, a huge thanks to Justin, Cres and Sean as well.
I don't like making a big deal out of my b-day but I'm 33 today and that was the best present ever. haha
I picked up a 40amp inline fuse, exhaust clamp and non-foulers for the second O2 sensors (since I'm catless) today. So tomorrow will be a full day of soldering and cleaning things up. Then finishing the exhaust hangers and sealing that up. Then get the damn jackstands out and hopefully give it a gingerly spin around the block. I've still got a ton of stuff to do but it's a great feeling to be making progress again.
I don't like making a big deal out of my b-day but I'm 33 today and that was the best present ever. haha
I picked up a 40amp inline fuse, exhaust clamp and non-foulers for the second O2 sensors (since I'm catless) today. So tomorrow will be a full day of soldering and cleaning things up. Then finishing the exhaust hangers and sealing that up. Then get the damn jackstands out and hopefully give it a gingerly spin around the block. I've still got a ton of stuff to do but it's a great feeling to be making progress again.
bullshark524
Member
- :
- 2000 mazda protege es soon to be 2000 mazda protege klze
o how exciting. happy birthday
fishdonotbounce
Registered Zombie
- :
- 08.5 CWP Speed3
Yea happy birthday from me too Evan. You're old (evil)
