GI: Replacement exhaust manifold

[SeR_Cyclops]

Looks good man! I want to see one fully welded up and ready to go!



[thepope540]

All in good time. I should have the wastegate here any day and then I'll be able to get that fitted up to the prototype and I'll hopefully be able to get a dump tube routed in the next couple weeks as well. Its going to be busy and I'm sure there will be a delay somewhere in the process but I'm looking forward to having these all sorted out and getting all the orders shipped.



[SCMP3]

So stoked. If I can get my rx7 motor and trans out and sold I will be sending some moneys



[Valk]

looking forward to seeing the finished product. Wont commit until then though. id like to save myself a couple hundred bucks buying your manifold for sure, but still on the fence about what to get.



[speedpx]

Any updates



[thepope540]

The first customer manifold is about 50% done, but I'm considering rerouting numbers 3 and 4. I'm going to tack some things together and post pics in a bit.



[StealthWyvern]

The first customer manifold is about 50% done, but I'm considering rerouting numbers 3 and 4. I'm going to tack some things together and post pics in a bit.

Take your time with mine as im not in a hurry right now for it. As long as it fits right and looks good thats all im worried about. Well as long as it doesnt take a year to get it. lol



[KrayzieFox]

The first customer manifold is about 50% done, but I'm considering rerouting numbers 3 and 4. I'm going to tack some things together and post pics in a bit.

I'll just bring this back up to help you get ideas



[2.0t03speed]

Where are those revised runner pics =)



[thepope540]

here you go

The prototype had runner lengths of 11.5", 8", 9", and 4". The revised routing has lengths of 11.5", 7", 6", and 8". It isn't perfect but I think its a good a can be with stock placement. I also worked the wastegate into the collector.



[highflyin285]

Looking good!



[SCMP3]

So the ewg will be right there on the mani? I know that sounds dumb. But I mean like no pipe off the mani to the ewg? Like to move it right off the mani? Looks good though



[SCMP3]

Im retarded. Guess I could just have something like this made when I have my screamer pipe done.



[StealthWyvern]

So the ewg will be right there on the mani? I know that sounds dumb. But I mean like no pipe off the mani to the ewg? Like to move it right off the mani? Looks good though

I'm curious to see how he pulls off the EWG on the new routing. I do like how the pipes actually fit closer to the flange.

Im retarded. .

Well no one is arguing that part... lol



[SCMP3]

Haha nice. Which ewg are you gonna get stealth?



[2.0t03speed]

lol it definitely looks interesting now.



[StealthWyvern]

Haha nice. Which ewg are you gonna get stealth?

I'm looking at getting a 38mm Tail v-band (I think its a MVS but not sure) when my car is paid off. Only roughly 3 more months tell then! I might end up having to do a adaptor/placement adjustment pipe like you posted earlier. No idea wtf that this is called. When I get the manifold and EWG installed. I plan on getting the turbo clocked and my hot pipe redone.

lol it definitely looks interesting now.

Not 100% sure if I like the looks of the new routing to be honest but I want to wait and see how he manages the EWG portion to really comment to much.



[2.0t03speed]

Not 100% sure if I like the looks of the new routing to be honest but I want to wait and see how he manages the EWG portion to really comment to much.

+1 but im going to hold out for the finished product. i was really digging the first prototype though lol.



[SCMP3]

Same ewg I want.



[Cleverfrog]

looking like that bolt under the short pipe is going to be a PITA now.
