You know what needs to be a sticky??

:
Mazda P5
What the MP5 upgrades are.

I Am NOT taking full credit for the info listed, I pulled 99% of this info off of www.mazdas247.com and just thought it would be useful to be found all in one place so most people can refer to this as a guide. Perform at your own risk, but these mods have all been done and should work IF done properly.

VTCS delete on the top portion of the intake manifold (plug the hole with a bolt)

DO NOT delete the VICS (creates more torque for N/A setups) unless you turbo,

The VICS are in the middle and round, Do NOT get mixed up with the VTCS, pair with the MP3 ECU (140hp - 142tq) or Reflash the MP5 ECU to mirror MP3.

An aftermarket header, you will have to adjust the EGR valve and put on a non fouler for no codes.
-OBX
-AWR
-Pacemaker
-Mazda 626 header (http://www.mazdas247.com/forum/showthread.php?123793444-HOW-TO-Mazda-626-Headers-on-2.0-Protege)

-CAI, several choices out there depending on where you want it, and some you will just have to turn the coolant reservoir around.


-1.8l coil conversion with the 626 valve cover, coils, and spark plug wires,
Also you can use the v6 oil filter (2000 626).
WIX XP Oil Filter number: 51356
-Mazda 626 single runner intake manifold

Brake upgrade for the front and rear. I believe using the mazda 6 rear calipers you need to modify the e-brake.
Front: (Height | Width | Weight)
2006-09 Mazda6 (v6) : 299mm | 25mm | 19lbs
2003-05 Mazda6 (v6) : 282mm | 25mm | 14.8lbs
2003-03.5 Mazda MSP: 273mm | 24mm | 13.5lbs
2002-03 Mazda Pro5 : 257mm | 24mm | 12lbs

Rear: (Height | Width | Weight)
2006-09 Mazda6 (v6) : 280mm | 10mm | 9.3lbs
2003-04 Mazda6 (v6) : 280mm | 10mm | 9.3lbs
2003-03.5 Mazda MSP: 280mm | 10mm | 9.3lbs
2002-03 Mazda Pro5 : 261mm | 10mm | 9lbs
THERE IS NO MODIFICATION REQUIRED, TAKE YOUR OLD CALIPERS/PADS/ROTORS AND PUT IN THE NEW CALIPERS/PADS/ROTORS AND DRIVE AWAY, COMPLETE BOLT ON.
NOTE: if and when purchasing new setup make sure you get the caliper brackets as well

Adding turbo using the MSP setup:
MSP turbo
MSP exhaust manifold
MSP s-pipe
IC setup and piping
Oil feed/return lines
MSP ECU
Tap in either oil pan or crank case
Stronger Clutch
FMIC
Of course all of those parts can be replaced by something better but of similar nature (eg GT28RS instead of the MSP GT2554R).

Rear Sway Bar:
-MSP (front sway bar works as well)
-Racing Beat
-Progress
-AWR

Rear Strut Tower Bar:
-MX-6 bar
-AWR
-Megan
-Carbing

-You can do the FS-ZE engine swap for higher compression N/A build. You would need to swap over all of the FS-DE sensors so you won't throw any codes.
FS-ZE cams can be swapped over to the FS-DE
-Also you can do KL swap:
http://www.mazdas247.com/forum/showthread.php?123829343-Protege-KLZE-KLDE-V6-swap-thread

Mazdaspeed/ JDM cam
Also shifter bushings:
http://corksport.com/mazdaspeed-protege/

Lowering/Springs/Coilovers:
(Please note that not all of these options may still be in production. Some may only be available used.)
http://www.mazdas247.com/forum/showthread.php?58798-**-Spring-Buyer-s-Guide-**

Last edited:
Also, a common problem door lock actuators:
http://www.carparts.com/details/Maz...r/2003/Base/4_Cyl_2-dot-0L/072415-01-PLK.html

Things to Note:
-The Protege5 can accommodate either a single din or double din headunit.
-2003 P5s were equipped with factory tweeters in the sail panels of the front doors. You may or may not wish to disconnect these if you upgrade your front speakers.
-2003.5 P5s were equipped with a factory powered subwoofer that was mounted on top of the spare tire, under the carpet
-Front Doors: 5x7" or 6x8" may be used. 2.75" deep.
Rear Doors: 6" or 6.5" may be used. 4.25" deep.

P5 WIX oil filter: 51365
626 WIX oil filter: 51356

Light sizes:
Low Beams - H7
High Beams - 9005
Fog Lights - H3
Corners - 194, 168 Sidemarker - 194, 168
Front Signal/Parking - 1157NA
Dome - 3022, DE3175
Rear Signal - 7440, 210Y
Map Lights - 194, 168
Trunk - 194,168
Tail/Stop - 7443
Plate - 3652

Shift knob size: 10x1.25 - 7/16

Antenna swap:
CX-7, S2000, RDX, MPV or Aftermarkets.

Wheels: Things to Note
Tire sizes:
195/50-16*
205/50-16
205/45-16
205/55-16
215/45-16
P5s, along with many other Mazdas, use a 5x114.3 MM lug pattern
Wheels with a diameter greater than 17" may require a very low profile tire and/or fender rolling, depending on your suspension set-up

Front Lips:
-2003.5 Mazdaspeed Protege
-A WRX lip may be mounted under the MSP lip
-DG
-Autoexe
-s204
-Subaru Chargespeed
-JDP carbon fiber splitter
-Garage Door Seal lip (AKA HomeDepot Lip)

Grills:
DGM carbon fiber grill
--DGM fiberglass grill
-Autoexe grill

Carbon Fiber Hoods:
-DGM
-VIS

Side Molding Removal:
http://www.mazdas247.com/forum/showthread.php?4737-How-To-Shaving-Side-Moldings

Headlights:
-Swap P5 headlights for Sedan(Very simple headlights Proteg5 have 4 son, 2 positive and 2 power setting has negative mass!
Have connected 1 of 2 alimentaton positive on the center connector of the bulb and connect the 2 up to ground connectors on each side of the bulb!
Over the remaining power is condemned it is useless and does not connect with the other food!)
-Canadian Headlights (Black Housing)
-DIY black housings

Fog Lights:
-2003.5 Mazdaspeed Protege fog light deletes.
-Foglight vinyl overlays.
-Foglight Rewiring (Note: Stock wiring only allows the foglights to be turned on when the headlights are on):
Foglight switch turns foglights on, regardless of headlight switch position (http://www.mazdas247.com/forum/showthread.php?123767000-fog-lights-always-on)
Foglight switch turns foglights on, when parking lights or headlights are on(http://www.mazdas247.com/forum/showthread.php?123764331-how-to-foglight-mod.-*with-pics*)

Mazda6 Rear Wiper:
http://www.mazdas247.com/forum/show...Wagon-Wiper-on-P5&highlight=mazda6+rear+wiper

Swap a switch for intermittent settings:
-1999-2006 Mazda MPV
-Ford Escape
-Mazda Tribute
-Mazda 626 (This option will result in the loss of rear wiper control)

Miscellaneous:
-Mazda Tribute washer nozzle swap
-DaveB aluminum gauge rings

Last edited:
Done! I took the useful info from that post. Hopefully people are smart enough to know they can paint or plastidip their plastic interior and rims.
Now I will continue to monitor and update accordingly so myself and others have useful info. Now if a Mod can change the title and sticky this, that would be amazing.

I've been wanting to make a post like this myself, but i'm a lazy bum. Thanks for taking the initiative! Great info! (thumb)

Thanks. I want to put in the 5th gear swap but I can't find any info in it. What year and models because the website that used to sell them no longer exists.

CDM grill, JDM cupholders, MP3 splitter, JDM console extension, GT Spec everything - Trailing Links/LTB/FR STB/RR STB/Ladder Brace/Vbrace/Reinforcement panel, JDM footwell lighting kit, HID projector retrofit headlights, MSP door sills, MSP floormats, MSP/MP3 pedal covers, HID oem fog mod, cut off VTCS rod even with first IM runner instead of doing screw and having dangling actuator, MSP ECU even if no turbo and if manual trans, MSP VC with engine cover................I'm sure I missed more.

This is great! subbed

And I can't believe no one mentioned the JDM tail light swap! Probably the most popular and easiest plug-and-play mod for the P5.

CDM rubber trunk mat

swapping the deeper 03.5 cup holders into any previous year

CDM extended armrest

Ford Escape(?) Moog endlinks,
adjustable end links- AWR, Racing Line
http://www.racinglineperformance.com/shop/pc/viewCategories.asp?idCategory=16

Nardi steering wheels

Roof rack delete strips- completely removes the runners

Last edited:
