Rear endlinks swaybar

CHIQLES

Member
Contributor
:
mazdaspeed protege #0403
I replaced the rearendlinks after i noticed they were cracked i used the napa 190mm

heres a pic of ny damaged ones

heres the new ones they are a little beefer


they fit with no problem

has anyone replaced there front endlinks and with what and does the p5 front endlinks work?

what about the ford escape endlinks i read about anyone useing thoughs?

im really enjoying the new endlinks car feels sharp and i havent heard the clunk but its still pretty early.
But i hopeing the best with this brand Napa says its there best selling brand and have had no complaints. I went ahead and orderd the front links as well. Ill do a comparison of thoughs when i pull them..

Just installed the AXR bracket on my car, but I am still getting an annoying rattling sound from the rear of my car. Where you having the same symptoms?

ya i mean it was the regular boxex in the trunk noise but it seems gone now i have been focusing on trying to hear it but there little to no noise not like before.

so i made it my goal to hit as many bumps as I could on the way to work today. Yes the car is 100% quieter and funner to drive..

did the fronts today

heres the comparison

heres the first one i took out was a small pain bolt was stripped a little bit but hammer and deep socket with impact gun and good to go..

the nut is 14mm and allen head is 5mm sometimes you may need to do this if the nut just rotates

same deal when putting them on except the new nut is 17mm if you have rachet wrenches youll be happy when you encounter this.

im done for now but im off to the store to buy a rachet 17mm wrench for next time..

heres the finish product

and remember bothe sides must be equally raised so you can manipulate the bar to push the studs through without problem

car is quiter while i had the front up i sprayed the spring pads with w40 someone sugested that on another thread.

car is quiter while i had the front up i sprayed the spring pads with w40 someone sugested that on another thread.

Hmm, I'm thinking I might just have to replace the end links. I'm still getting that rattling noise from the rear of my car.
