My Ride After This Years Build

[kz9]

More pics to post later, after I wash her....



[ForceFed]

Nice....
I see a nice Wet kit in there as well...The only way to run nitrous..If you ask me.

This is absolutley one of the nicest (yet busy) Engine compartments I have seen on the forum.

Props to you.



[kz9]

I don't like the hoses either, but i needed to rush it a bit because I have emissions on Aug 10th. I'm gonna clean them up a bit



[justanothermp5]

holy huge intercooler!!
nice build though, were do you live?
normally i just slip 20 bucks on the dash over here in NC and they pass me lol



[kz9]

^ Canada



[NCZ13]

holy crap thats a ton of guages.

Clean build tho cant wait to see some vids =D



[BLKOUT MSP]

wow man thats a crazy build. Good luck. What kind of power do you think its gonna make?



[altspace]

I agree, you need more gauges to look at while driving. Got a co-pilot?



[snuggles1300]

lol ....pimped fing ride nice job ....super cuddos to you



[Crazee D]

holy smokes! you could buy a new car with the cost of accessories alone!

I love it!



[Crazee D]

Dude, is that an Innovate XD-16 gauge in the glovebox? Slick



[hazeXban]

Sick..



[sandspeed]

wow awesome man! what are the specs?



[magnumP5]

Holy hell that's a lot of gauges and braided line! Man, and I thought having five gauges was a lot! Look really good though. Just have two questions for you:

1) What are all those gauges?
2) Why does it look like you have two air/fuel gauges (narrow and wide band?)



[jville]

(rockon) Baddass man.



[kz9]

2003 Mazda Protg

Motor built by Gary Leitch
www.Leitchperformanceengines.com



Performance:

Custom Turbo Kit (Garrett GT2871)
CP Pistons (8.3:1)
Puater Rods
Cleveite bushings and thrust washers
ARP hardware
Comentic head gasket
Heat treated, balanced, knife edged, and micro polished crank
Heat treated block
3 angle valve job
Port and polish head
Ported and Polished TB (58mm)
626 Extrude honed IM
Ported and gasket matched manifolds
TB and IM thermal spacers
525cc JDM STi injectors
Perrin fuel rail
Russell fuel dist. block
AEM FRP
MBX fuel rail adapter
225lhp Warbol fuel pump
Perrin IC with IC cooler rings (16x9 and 8x4)
ZEX 200hp shot direct-port wet nitrous kit with purge, bottle opener, TPS and traction switch with custom SS tubing
DEI Cryo system (fuel bar, intake bulb, IC cooler
Vibrant aluminium tubing, couplings and T-clamps
Vibrant vacuum block
Spectre SS braided vac hoses
Upgraded PCV
Greddy type R BOV
Nology Hot wires
Denso plugs
Greddy oil catch can
AWR radiator
Twin Spal 12inch fans and custom Aluminium mount
Greddy radiator breather
Greddy 1.3bar radiator cap
Samco radiator hoses
AWR oil pan
AWR engine mounts
Fildanza 7.5lbs flywheel (Lightened and balanced to crank)
Bully stage 3 clutch
Mazdaspeed revised and welded LSD
Tilton tranny pump and DEI 24x2 cooler coil
B&M short shifter
B&M oil cooler
Greddy E-manage
Greddy Profec E0-1 boost controller
Greddy turbo timer
Greddy Infometer
Innovate LM-1 wideband
Innovate X-16 gauge
Innovate LM-3 datalogger
J&S Safeguard
OEM upgraded alternator
Aeroquip hose and fittings (fuel, n2O, cyro)
3'' ID SS custom exhaust with flowmaster muffler
KVR cross-drilled and slotted rotors
KVR carbon pads
Goodrige SS braided line (clutch and brakes)

Suspension:

Tokico HPs struts
Eibach Prokit springs
AWR 21mm swaybar
AWR adjustable endlinks
GT spec front strut bar
Custom lower rear tie bar


Exterior:

Wings West body kit (moulded)
Shaved trunk
X-concept dual vented CF hood
DG Motorsport CF wing, mirrors, latch, air dam, eye lids
Custom CF fuel door
P5 antenna conversion
5% tint
5000k HIDs
CF tail lights
PIAA fog lamps
Streetglow undercar
LED marker conversion
Konig Holes 18''x7.5''
Falken rubbers

Interior:

MOMO R1 seats
MOMO steering wheel, shift nob, e-brake, pedals, and boots
DG CF panels (complete kit 12pcs)
Custom CF steering column gauge pods, passenger airbag, and shifter plate pods
Autometer shift light
Autometer Sport comp gauges (fuel press, a/f, volts, nitrous press, boost, egt, intake temp, oil press, oil temp, trans temp, cylinder temp, digital shift light
Custom glove box for E-manage and X-16 gauge
Custom middle console for EBC and Turbo timer
Streetglow black neon (22 tubes)
Streetglow blue neon (2 tubes in trunk)
PIAA interior bulbs
Custom fabric rear seats with Fire Extinguisher and Volt gauge
Custom rear deck for amp
Ignite CF switches


ICE:
----------
All Kenwood Excelon

7'' in dash monitor with DVD and TV tuner
6.5 front components
6x9 rear deck
2- 12'' subs
Mono block amp
6.5'' components on trunk lid
15'' Sanyo flat screen on trunk lid
--------

2-Phoniex Gold xs200 amps
Phoneix Gold cap
Tsunami wiring
Tsunami cap
Tsunami fuse blocks
Tsunami dist. blocks
Exide deep cycle
Custom enclosures with glass ports

Probably s*** that I missed, but this is a general idea



[EDM6-zoom zoom]

Nice build, do you have any exterior pics?



[kz9]

I'll post some more pics this weekend after I clean it up.



[ChopstickHero]

nice setup on the NOS



[MSP SuperStreet]

Great Ride and awesome build. Looking forward to seeing your performance numbers.
