Front Mount Pic Requests

[deVic]

Sup guys, I'm going to be making a custom intercooler setup for my msp. I'd like to see what the other companies like corksport, hi-boost, and perrin have for setups. i want to see pics of the piping (just to get an idea) and i want to see if you had to cut anything in the process. post pics of the piping and where it goes if you could.

Appreciate it



[alexB]

Heres 2 pics of the cutting I did.



[deVic]

awesome. i assume thats the perrin kit? if thats the perrin wheres the bar that comes with it?



[alexB]

No thats not the perrin kit. It is a custom kit I had made by a guy I know.



[deVic]

very nice.



[AtenzaNY62]

the pipings look sexyy lol



[TurbomanProtege]

this is the hiboost kit



[HondaNoMore]

alexB - is that an atmospheric BOV? do you not have a BPV? how does it run for you? what are the dimensions on your intercooler? pics with the bumper on? sorry, i'm REALLY curious about that setup, it looks AMAZING!



[alexB]

This is before I trimmed the tabs off for the stock grill.

Yes I am running open atmosphere.I am running the TurboXS rfl blow off valve. Its loud as hell. Sounds really good. I am not running the stock bpv anymore. I have relocated my mass air flow. It runs really good. I am not totally sure what the intercooler measurements are but I will get them for you by the end of the day.



[yellowmsp035]

i dont have any of my piping right now i dont think... ill look for some



[505zoom]

I just re-did all of my piping. Pics/writeup here:

http://www.mazdas247.com/forum/showthread.php?t=123693977
