AAC Wilwood SL-6 Big Brake Kit.

AAC Wilwood SL-6 Big Brake Kit. 6-piston Wilwood calipers, Wilwood BP10 street pads, AAC custom brackets and rotor hats, rotors, and Goodridge stainless braided lines. This big brake kit was on my Protege5.

17inch wheels or higher will be needed to fit this BBK. You can use the link below to see if the kit will fit.

http://www.aggressiveautoculture.com/resources/aac_resources_template_brakes.pdf

Comes with a set of new BP20 street brake pads. Supposed to be quieter. (Price $300) Buyer must pay shipping.

Good - BBK works perfectly and stops well. Comes with a extra set of brake pads.
Bad - Rotors need to be replaced, shop used hammer without my knowledge at the time to remove rotors. They were worn anyway.

Piston: 6 Piston Area: 4.12 Pad Volume: 4.9 Mount Description: 3.50" Lug Mount Rotor Width: 1.25 (with pads)
Caliper part # 120-6585-FS | 120-6584-FS

Information for rotor replacement

http://www.colemanracing.com/

Thickness = 1.25
Diameter = 13.0
Flange Diameter = 6.40
Eye Diameter = 9.10
Hole Size = .316
No. Holes = 8
Bolt Circle = 7.0
Front Face (Scallop out to ) = 8.75 Eye Diameter




















Last edited:
Damn....I see how they effed up the rotors!!...you didn't make them reimburse you ?? GLWS

I was pissed, and they almost lost the four screws. All they gave me was $300 off the bill. I should've probably pushed for more. I was selling my P5 at the time and had the shop remove most of the mods and change all the fluids for the next owner. The rotors were worn so I just accepted the $300 off the bill. Probably won't ever go back to that shop again.

I paid around $1300 for this kit I believe, it is a steal for $500!

Last edited:
Shocked no one has taken these. Lowering to $300 plus shipping. (eekdance)

Kit is in great condition, just needs replacement rotors. Collecting dust in my basement.

Last edited:

Maxx Mazda

Resident Asshole
Contributor
:
Completely Stock P5
I have this same setup, albeit it was a one off made waaaaay back in the day. Would you sell the spare pads?

:
Mazda 323 sp20
What type of replacement discs are they? Just so I can look them up and see how much to replace


Sent from my iPhone using Tapatalk

What type of replacement discs are they? Just so I can look them up and see how much to replace


Sent from my iPhone using Tapatalk

Here is the specs for the rotors. Someone who checked with colemanracing told me they were quoted around 200 per rotor.

Information for rotor replacement

http://www.colemanracing.com/

Thickness = 1.25
Diameter = 13.0
Flange Diameter = 6.40
Eye Diameter = 9.10
Hole Size = .316
No. Holes = 8
Bolt Circle = 7.0
Front Face (Scallop out to ) = 8.75 Eye Diameter
